ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6V 9Ah

Model Number : ER26500

Certification : CE, ROHS, UN38.3

Place of Origin : Wuhan

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 10000PCS/30Days

Delivery Time : 20 Days

Packaging Details : Carton

Brand Name : FBATTERY

Product System : Lithium Thionyl Chloride Aa Battery

Nominal Capacity : 9Ah

Nominal Voltage : 3.6V

Operating Temperature : ﹣60℃～+85℃

Weight : About 58g

Max. Continuous discharge Current continuous discharge current : 200mA

Max. Pluse Current : 400mA

Applications : Water meter, smoke alarm

Contact Now

ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6 V 9Ah


Lithium Thionyl Chloride Aa Battery Main Applications

>TPMS

>RFID .
>Alarms and security systems
>Beacons and emergency locationtransmitters
>GPS equipment>Metering sys tems
>Led lighting applications>OthersStorage
>Cells should be stored in a clean&dry(less than 30% RH) area>Temp. should not exceed +30* CWarning
>Do not use if cell casing is mangled>Do not use different model of cellin series


Lithium Thionyl Chloride Aa Battery Specification:

ModelER26500
TypeEnergy Type
SizeC
Nominal Capacity9000mAh(at 1mA, +25°C/2.0V cut off)
Nominal Voltage3.6V
OCV3.66V
Cut-off Voltage2.0V
Dimension26.2(D)*50.0(H)mm
Weight58g
Max. Continuous Current200mA
Max. Pulse Current400mA
Operating Temperature -60°C~+85°C
Storage TemperatureMax.30°C
Shelf Life≥10 years
Self Discharge Rate≤1%
CompatibilityCompatible with LS26500 , ER26500,LS26500C,TL-4920,TL-5920,TL-2200,SB-C01,SB-C02,SL-770,XL-140F,XL-145F



Dimension:

ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6V 9Ah


Discharge curves at(25℃)

ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6V 9Ah


Capacity-current Curves

ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6V 9Ah

Operating Voltage-Temperature Curve


ER26500 LiSOCL2 Lithium Thionyl Chloride Aa Battery 3.6V 9Ah
